● Bolt Material: Carbon steel in the grade of 4.8
● Nail Material: 45# Steel ( 38-42 HRC)
● Nuts: Flange nut
Hex Conical Washer Nut
● Finish: Yellow Zinc 6cr+
Yellow Zinc 3cr+
Blue White Zinc 3cr+
● Size: 1/4’’ 5/16’’ 3/8’’ 1/2’’ 5/8’’ 3/4’’; Length up to 6’’
-
Features
Pin/Nail: The pin is hardened to 38 - 42 HRC to ensure the holding strength. So Strike Anchor is specialized for areas that are located in the earthquake belt.
Easy operation: No special tools are required. Drilling the hole which is a little bit bigger than the diameter of the anchor that is being installed. Then use a hammer to drive the nail to expand the anchor
Applications
Strike anchors should be used in solid concrete and should never be installed in any other type of masonry material. It also can be used in the following situations
● Machine fabrications
● Assembly line
● Fastening the shelves, lifting machine, and steel structures
Regular Size Following
Size Thread Length Size Thread Length 6*45 19-22 1/4*1-3/4 15-18 6*60 15-18 1/4*2-3/8 19-22 8*50 19-22 5/16*2-3/4 19-22 8*70 19-22 3/8*2-3/8 24-27 10*60 24-27 3/8*3-1/2 29-32 10*80 24-27 1/2*2-3/4 24-27 10*100 29-32 1/2*3-1/2 29-32 10*120 29-32 1/2*4-3/4 39-42 12*70 24-27 1/2*6 49-52 12*90 29-32 5/8*4 39-42 12*100 29-32 5/8*6 49-52 12*120 34-37 3/4*6 49-52 12*150 34-37 16*100 39-42 16*120 39-42 16*150 39-42 Installation
-
